    Horizontal Boring Machine Tos W100

    Product Details:

    X

    Product Description

    Horizontal Boring Machine TOS W100

    We have successfully achieved a high level of customer appreciation resulting in long-lasting relations by offering products that are high in quality. We purchase all of our products directly from their origin places to provide excellence in both quality and price. All of our machinery offered,including Horizontal Boring Machine TOS W100 is precision engineered, to provide high operational benefits to the user entities.


    Description:

    • Machine Type: Horizontal Boring Machine
    • Machine Make: TOS
    • Machine Model: W100


    Features:Easy Installation Pocket friendly prices Minimum Maintenance.

    Technical  Specifications:

    Table Type

    Rotary

    X-Axis

    1600 mm

    Y-Axis

    1120 mm

    Z-Axis

    1250 mm

    W-Axis

    900 mm

    Facing Chuck

    600 mm

    Size Of The Table

    1250 x 1250 mm

    Dimension L X B X H

    6020 x 3000 x 3500 mm

    Weight Of The Machine

    14000 Kg

    Size Of The Spindle

    100 mm

    Speed Of The Spindle

    7-1120 RPM

    Feeds For Milling (18 Stages)

    18-900 mm/min

    Feeds For Boring (32 Stages)

    0,02-12 mm/rev

    Thread Cutting Range (Metric)

    0,25-12 mm

    Rapid Traverse

    2800 mm/min

    Max Work-Piece Weight

    3000 Kg

    Total Power Consumption

    15 KVA

    Buy used Horizontal Boring Machine TOSW100 in very good working condition at a very competitive price.
