    DEEP HOLE DRILLING MACHINE

    DEEP HOLE DRILLING MACHINE

    Product Details:

    X

    Product Description

    Deep  Hole Drilling Machine


    We have successfully achieved a high level of customer appreciation resulting in long-lasting relations by offering products that are high in quality. We purchase all of our products directly from their origin places to provide excellence in both quality and price. All of our machinery offered including Deep Hole Drilling Machine  is precision engineered, to provide high operational benefits to the user entities.



    Features:

    Flawless performance, High functionality, Less maintenance, Long functional life



    Technical Specifications:



    Height Of Central Axis Over The Bed

    500 mm

    Range Of External Work-Piece Diameters

    In A Roller Lunette

    80 - 600 mm

    In A 4-Cam Chuck

    80 - 500 mm

    Range Of Work-Piece Length

    1000 - 3000 mm

    Range Of Opening Diameters (Boring)

    50 - 400 mm

    Max. Work-Piece Weight

    4000 Kg

    Max. Stroke Length Of Stem Headstock

    4000 mm

    Range Of Spindle Rotation Frequencies

    Of Work-Piece Headstock

    22.4 - 355 RPM

    Of Stem Headstock

    Without Rotation

    Range Of Working Feeds Of Stem Headstock

    5 - 3000 mm/min

    Rapid Feed Of Stem Headstock

    5000 mm/min

    Max. Torque Of Stem Headstock

    at least 8.8 KN/m

    Max. Productivity Of Pumping Station SOZH

    1000 L/min

    Max. Pressure SOZH

    At 200 L/Min

    4.0 MPA

    At 400-600 L/Min

    3.0 MPA

    At 1000 L/Min

    2.0 MPA

    Power Of Work-Piece Headstock Drive

    55 KW

    Gearbox Power

    10.5 KW

    Total Power Of All Electric Motors Installed

    117 KW

    Overall Machine Dimensions(LXWXH)

    15700 x 4555 x 2020 mm

    Machine Weight (Including Electric Equipment)

    34150 Kg



    Buy used Deep Hole Drilling Machine in very good working condition at a very competitive price.
